Datacard Sigma DS1, Simplex, 125-Card Input Hopper

Standard Features and Supplies

Print Technology

• Dye-sublimation / resin thermal transfer
• Rewritable technology

Print Capabilities

• Single-sided

Print Resolution

• 300 dots per inch (dpi) (300 X 600, 300 X 1200)

Monochrome printing

• Up to 660 single-sided cards per hour

Print Speed

• Full color printing
• Single-sided color ribbon - Up to 175 cards per hour (cph)

Card Capacity

• Input hopper - up to 125 cards
• Output hopper - up to 25 cards (up to 100 optional)

Card Sizes

• Card input size:
• Thickness - 0.010 inches to 0.040 inches
  • (0.25mm - 1.016mm)
• Dimension - ID-1, CR-79, CR-80

Operating Environment

• Temperature: 60°F to 95°F (15°C to 35°C)
• Humidity: 20-80 % RH - non condensing

Physical Dimensions

• L 17.4 in x W 8.9 in x H 9 in / 44.2 cm x 22.6 cm x 22.9 cm

Weight

• 11.3 lbs (5.49 kg)

Connectivity

• USB

Warranties

• 36 Months

Operating system support for printer driver

• Windows 11
• Windows 10 versions, 32- and 64-bit
• Windows 8.1, 32- or 64-bit
• Windows Server 2019
• Windows Server 2016
• Windows Server 2012, R2, 64-bit

Optional Features and Supplies

Magnetic Stripe Encoding

• ISO 7811 three-track support (high- and low- coercivity)
• JIS Type II Single-track option

WiFi

• Wi-Fi types: 802.11g/n
• Authentication modes: None, WPA2 Personal
• Dual-band 2.4GHz & 5GHz

Smart Card Encoding

• Loosely coupled
• Contact smart card encoding: ISO 7816 T=0 (T=1),
• Class A 5V (3V and 1.8V)

• Contactless smart card encoding: ISO 14443 – A (B),
• ISO 15693, MiFare Series, DESFire Series,
• HID IClass Series, HID Prox (125 KHZ)

Color Ribbons

• Prefilled ribbon cassettes:
  • YMCKT (500)
  • KTT (750)
• Refill ribbon kits:
  • YMCKT (250/500)
  • ymcKT (650)
  • KT (1000)
  • KTT (750)
  • YMCKF-KT (300)
  • YMCKL-KT (300)
