JBL BassPro Lite 7" 200 WATT Car Subwoofer

JBL BassPro LITE delivers deep bass and takes up ultra-compact space.

JBL’s smallest powered subwoofer can be hid in the most compact of locations and deliver exceptional performance to any car audio system. Powered by a 100Watts Amplifier, BassPro LITE delivers accurate, tight bass you would expect from JBL, all while running cool and drawing minimal current from your vehicles charging system.

• Big Bass,ultra-compact space
• Upgrade easier, Connected in series
• Intelligent Electronic Design for Reliable and Extraordinary Performance
• Die-Casting Aluminum Enclosure Design
• Bass boost Volume Control

Big Bass,ultra-compact space

JBL BassPro LITE delivers deep bass and takes up ultra-compact space. Its onboard 100Wrms amplifier has been performance matched to subwoofer to deliver tight, accurate bass.

Upgrade easier, Connected in series

JBL BassPro LITE can be connected in series for user upgrade to purchase 2 set devices. The secondary BassPro LITE is still adjusted by them-self without extra Power / Single complex wires

Intelligent Electronic Design for Reliable and Extraordinary Performance

The BassPro LITE employs high-pass filters and limiters that deliver exceptional at-the-limits performance.

Die-Casting Aluminum Enclosure Design

The all-die-cast aluminum enclosure design is not only Ultra-compact size, but the ALL IN ONE is combined elegant JBL industry design element and powerful acoustic performance.

Bass boost Volume Control

Bass boost Volume control is intergraded on I/O panel to let you adjust the sound freely

What’s in the box?

• 1x Under seat subwoofer
• 4x Screws
• 2x Wiring harness for power and speaker level input (300mm)
• 1x 15A Fuse

Specifications

Driver Complement

super powerful 7”(178mm) Subwoofer

Amplifier Power

Class D, 100Wrms; 200W Max

Frequency Response

30Hz – 150Hz

Fuse

15A

Maximum Current Draw

15 A

Quiescent Current Draw: Input Sensitivity

0.18 V – 5.0 V Low-

Level Input

0.75 V – 20V High-Level Input

Crossover Frequency

50 Hz – 150 Hz

Crossover Slope

12 dB/octave

Bass Boost

0dB to + 12dB @ 50Hz

Dimensions (L x W x H)

10-1/4” x 8” x 2-9/16” (259.6mm x 203.1mm x 65.5mm)

Weight

8 lbs (3.5kg)
